Kia Stinger I (2017-2021) atm sol Wiring diagram
This page shows the only wiring diagram for the component.atm sol, which is found in the car Kia Stinger I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram atm sol (1 of 1)
A/BAG IND FUSE
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
AST
ATM SOL
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
ECU GROUND
EXTERNAL BUZZER
GRN WIRE
GRY/BLK WIRE
HAZARD SWITCH
HEADLAMP HI SWITCH
HEADLIGHTS SYSTEM
I/P-E
IBU
ICU JUNCTION BLOCK
LF SEARCHING ON
LIN RAIN SENSOR
MODULE 7 FUSE
NAVIGATION SYSTEM
ORG/ WIRE
PDW-F GROUND
PDW-F POWER
PDW-F/R INPUT
PDW-F/R SWITCH I/P
PDW-R POWER
POWER DISTRIBUTION SYSTEM
POWER TOPS SYSTEM
PUDDLE/POCKET LAMP
RAIN SENSOR (GROUND)
REAR CTR
RED WIRE
RELAY ENERGIZED
SECURITY INDICATOR
SHIFT INTERLOCK SYSTEM
SSB ILL POWER
START F/B SIGNAL
START RELAY OUTPUT
STARTING/CHARGING SYSTEM
SUNROOF STATUS
WHEEL SENSOR SIGNAL (RR)
WHT WIRE
WHT/BLK WIRE
WIPER 'P' POSITION
WIPER B/UP SWITCH SIGNAL
WIPER HIGH RELAY CONTROL
WIPER LOW RELAY CONTROL
WIPER POWER RELAY CONTROL
WIPER, LIGHT GROUND
WIPER/WASHER SYSTEM
WIPER/WASHER, EXTERIOR LIGHTS SYSTEMS
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Integrated control unit circuit (2 of 2) -> ATM SOL
