Kia Stinger I (2017-2021) aeb ind Wiring diagrams
This page contains all the electrical diagrams for the component. aeb ind, in which he is found in the car Kia Stinger I (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram aeb ind (1 of 3)
2.0L TURBO
3.3L TURBO
ABS IND.
AEB IND
AUTO HOLD IND (AMBER)
AUTO HOLD IND (GREEN)
AUTO HOLD IND (WHITE)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE FLUID LEVEL SENS
BRAKE FLUID LEVEL SENSOR
BRAKE LAMP
BRAKE LIGHT
BRAKE TEST
BRN WIRE
BRN/ORG WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMING CONTROL
E/R JUNCTION BLOCK
ELECTRONIC ATM SHIFT LEVER
ELECTRONIC VACUUM PUMP
EPB IND
ESC IND
ESC OFF IND
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HALL IC OUT DIR
HALL IC OUT GND
HALL IC OUT PWR
HALL IC OUT SPD
HOT AT ALL TIMES
I/P-C
I/P-F
I/P-G
IBU
ICU JUNCTION BLOCK
INSTRUMENT CLUSTER
IPS CONTROL MODULE
MICOM
NCA WIRE
ORG/ WIRE
PARKING BRAKE IND.
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT ELECTRONIC PARKING BRAKE ACTUATOR
SIG (RR)
SIG 3 GND
SPEED INPUT
STOP LAMP
STOP LAMP SW
TRANSCEIVER/
VACUUM PUMP FUSE
VACUUM PUMP RELAY
VEHICLE
WHEEL SENS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, w/ epb (3 of 3) -> AEB IND
Wiring diagram aeb ind (2 of 3)
2.0L TURBO
3.3L TURBO
ABS IND.
AEB IND
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SENS
BRAKE FLUID LEVEL SENSOR
BRAKE LAMP
BRAKE LIGHT
BRAKE TEST
BRN WIRE
BRN/ORG WIRE
C-CAN
C-CAN HIGH
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
ELECTRONIC ATM SHIFT LEVER
ELECTRONIC VACUUM PUMP
ESC IND
ESC OFF IND
FOOT PARKING BRAKE SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
I/P-C
I/P-F
I/P-G
IBU
ICU JUNCTION BLOCK
INSTRUMENT CLUSTER
IPS CONTROL MODULE
MICOM
MSDI
ORG/ WIRE
PARKING BRAKE IND.
PARKING BRAKE SWITCH
PNK WIRE
RELAY ENERGIZED
SIG (RR)
SIG 3 GND
SPEED INPUT
STOP LAMP
STOP LAMP LOW SW
VACUUM PUMP FUSE
VACUUM PUMP RELAY
VEHICLE
WHEEL SENS
WHT/BLK WIRE
Go to component -> Anti-lock brakes circuit, w/o epb (3 of 3) -> AEB IND
Wiring diagram aeb ind (3 of 3)
7 COLOR TFT TFT CONTROL SIG (LVDS) 3.5 MONO TFT LCD TFT CONTROL SIG
ABS IND.
AEB IND
AMBER IND
AUTO HIGH BEAM IND
AUTO HOLD (AMBER) IND (CONVENTIONAL)
AUTO HOLD (GREEN) IND (CONVENTIONAL)
AUTO HOLD (WHITE) IND (CONVENTIONAL)
AUTO STOP (AMBER) IND
AUTO STOP (GREEN) IND
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CHARGE IND
CHECK ENGINE IND
CLUSTER FUSE
CLUSTER SPEAKER
COMPUTER DATA LINES SYSTEM
CONSTANT
CONSTANT CURRENT
CRUISE CONTROL SYSTEM
CURRENT
DBL IND
DIAL ILL (WHITE)
DIMMING CONTROL
DIMMING CONTROL (CONVENTIONAL)
EPB IND
ESC IND
ESC OFF IND
FLASH MEMORY
FUEL SENDER
GRN WIRE
GRY WIRE
HDA IND (CONVENTIONAL)
HIGH BEAM IND
HOT AT ALL TIMES
I/P-F
ICU JUNCTION BLOCK
IMMO IND
INSTRUMENT CLUSTER
LDW/LKA-L/R
LDW/LKA-L/R (GREEN) IND (CONVENTIONAL)
LDW/LKA-L/R (WHITE) IND (CONVENTIONAL)
LEAK CURRENT AUTO CUT DEVICE
LED HEADLAMP IND
LEFT TURN IND
LOW BEAM IND
LOW FUEL IND
MASTER IND
MDPS IND
MICOM
MONITOR
MULTI MEDIA 3 FUSE
NCA WIRE
OIL PRESSURE IND
ORG/ WIRE
OVER SPEED IND
PARKING BRAKE IND.
PNK WIRE
POINTER ILL (RED) WIRE
REAR FOG IND
RED WIRE
REG
RELAY ENERGIZED
RHEOSTAT DOWN IN
RHEOSTAT UP IN
RIGHT TURN IND
SEAT BELT IND
SUPERVISION
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL ON IND
TFT BACK ILL (WHITE)
TO PIN 25 (DIAGRAM 3 OF 3)
TPMS IND
TRANSMISSIONS SYSTEM
TRIP SWITCH (-) IN
TRIP SWITCH 1 (+) IN
TRIP SWITCH 2 (+) IN
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> AEB IND
