Ground distribution circuit for Kia Sportage V (2021-2024)

2.0L TURBO 2.4L A/C CONTROL MODULE AUTOMATIC A/C BCM BLK WIRE BLK/WHT WIRE CLOCKSPRING CRASH PAD SWITCH (LOWER) DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER SEAT BELT BUCKLE SENSOR FET (FIELD EFFECT TRANSISTOR) FRONT POWER OUTLET 1 (FRONT CIGARETTE LIGHTER) FRONT POWER OUTLET 2 GLOVE BOX LAMP/ SWITCH GRN/BLK WIRE HAZARD SWITCH HIGH MOUNTED STOP LAMP HOOD SWITCH I/P-E ICM RELAY BOX TWO TURN UNLOCK RELAY INSTRUMENT CLUSTER LEFT LICENSE LAMP LEFT REAR COMBINATION LAMP (IN) MANUAL A/C NCA WIRE PASSENGER OCCUPANT DETECTION SENSOR PASSENGER SEAT BELT BUCKLE SENSOR POWER TAILGATE BUZZER POWER TAILGATE LATCH REAR VIEW CAMERA, TAILGATE HANDLE SWITCH REAR WIPER MOTOR RED WIRE RIGHT FRONT FOG LAMP RIGHT HEADLAMP SMART JUNCTION BLOCK SMART KEY CONTROL MODULE SRS CONTROL MODULE START/STOP BUTTON SWITCH STEERING WHEEL HEATER MODULE STEERING WHEEL) SUNROOF MASTER CONTROL UNIT (GLASS) SUNROOF SLAVE CONTROL UNIT (ROLLER) TAILGATE LATCH VACUUM PUMP WASHER LEVEL SENSOR WASHER MOTOR

BCM BLK WIRE CENTER FASCIA LAMP CLUSTER IONIZER CRASH PAD SWITCH DATA LINK CONNECTOR ELECTROCHROMIC MIRROR GRY WIRE I/P-E IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IMMOBILIZER MODULE IPS CONTROL MODULE LEFT FORWARD PARKING DISTANCE WARNING SENSOR LEFT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER) LEFT FRONT VANITY LAMP LEFT REAR PARKING ASSIST SENSOR LEFT REAR PARKING ASSIST SENSOR (CENTER) LEFT REAR PERSONAL LAMP MULTI- FUNCTION SWITCH MULTI-FUNCTION CAMERA UNIT OUTSIDE MIRROR FOLDING RELAY OUTSIDE MIRROR UNFOLDING RELAY OVERHEAD CONSOLE LAMP PANORAMA SUNROOF SWITCH RIGHT FORWARD PARKING DISTANCE WARNING SENSOR RIGHT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER) RIGHT FRONT VANITY LAMP RIGHT REAR PARKING ASSIST SENSOR RIGHT REAR PARKING ASSIST SENSOR (CENTER) RIGHT REAR PERSONAL LAMP ROOM LAMP SMART JUNCTION BLOCK W/ SUNROOF W/O SMART KEY W/O SUNROOF WIRELESS CHARGER

2.0L TURBO 2.4L A/V, NAVIGATION HEAD UNIT AUDIO BLK WIRE BLK/ORG WIRE BLOWER RELAY BRAKE FLUID LEVEL SENSOR COOLING FAN 1 RELAY COOLING FAN MOTOR E/R JUNCTION BLOCK E/R-A E/R-B EXTERNAL BUZZER FORWARD COLLISION AVOIDANCE ASSIST MODULE FRONT DEICER FRONT WIPER (LOW) RELAY FRONT WIPER HIGH RELAY FRONT WIPER MOTOR HORN (HIGH) HORN (LOW) KEYBOARD LEFT FRONT FOG LAMP LEFT HEADLAMP MIC SHIELD MULTI-PURPOSE CHECK CONNECTOR NCA WIRE PCB BLOCK PDM (ACC) RELAY POWER OUTLET RELAY STOP LAMP SWITCH USB ILLUMINATION W/ NAVIGATION W/ SMART KEY W/O NAVIGATION

10-WAY 2 WAY 2.0L TURBO 2.4L ATM SHIFT LEVER ATM SHIFT LEVER ILLUMINATION BATTERY BATTERY JUNCTION BLOCK BLK WIRE BLK/GRN WIRE BLK/YEL WIRE DRIVER DOOR LOCK ACTUATOR DRIVER POWER OUTSIDE MIRROR DRIVER RECLINING LIMIT SWITCH DRIVER SAFETY POWER WINDOW MODULE DRIVER SEAT MANUAL SWITCH DRIVER SMART KEY OUTSIDE HANDLE ESC MODULE GRN/BLK WIRE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 MDPS UNIT NCA WIRE PCM POWER OUTSIDE MIRROR SWITCH POWER WINDOW MAIN SWITCH REAR USB CHARGER W/ EPB

10-WAY 2 WAY AMP BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE CONSOLE SWITCH FRONT AIR VENTILATION SEAT CONTROL MODULE FRONT SEAT WARMER CONTROL MODULE FUEL PUMP CONTROL MODULE GRN WIRE LEFT BLIND SPOT DETECTION RADAR LEFT REAR BUMPER LAMP LEFT REAR COMBINATION LAMP (OUT) LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW SWITCH NCA WIRE PASSENGER AIR VENTILATION SEAT BLOWER MOTOR PASSENGER DOOR LOCK ACTUATOR PASSENGER POWER OUTSIDE MIRROR PASSENGER POWER WINDOW SWITCH PASSENGER RECLINING LIMIT SWITCH PASSENGER SEAT MANUAL SWITCH PASSENGER SMART KEY OUTSIDE HANDLE POWER TAILGATE MODULE POWER TAILGATE SWITCH REAR DEFOGGER REAR POWER OUTLET REAR SEAT WARMER CONTROL MODULE RIGHT BLIND SPOT DETECTION RADAR RIGHT LICENSE LAMP RIGHT REAR BUMPER LAMP RIGHT REAR COMBINATION LAMP (IN) RIGHT REAR COMBINATION LAMP (OUT) RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR POWER WINDOW SWITCH W/ AUTO UP/DOWN, SAFETY W/ EPB W/ POWER SEAT W/O AUTO UP/DOWN, SAFETY W/O VENTILATION
