Kia Sportage V (2021-2024) Computer data lines circuit

2.0L TURBO 2.4L A/C CONTROL MODULE A/V, NAVIGATION HEAD UNIT AUDIO AUTOMATIC A/C B-CAN HI B-CAN LO BLK WIRE BLU WIRE BRN WIRE C-CAN HI C-CAN LO DATA LINK CONNECTOR GRY/ORG WIRE HOT AT ALL TIMES I/P-F INSTRUMENT CLUSTER IPS CONTROL MODULE M-CAN HI M-CAN LO MANUAL A/C MODULE 8 FUSE PCM PNK WIRE RED WIRE SMART JUNCTION BLOCK SMART KEY CONTROL MODULE W/ NAVIGATION W/O NAVIGATION WHT WIRE WIRELESS CHARGER YEL WIRE

AMP B-CAN HI B-CAN LO BCM BLU WIRE BRN WIRE C-CAN HI C-CAN LO GRN WIRE GRY WIRE GRY/ORG WIRE IMMOBILIZER MODULE K LINE M-CAN HI M-CAN LO MDPS UNIT MULTI-FUNCTION CAMERA UNIT NCA WIRE ORG/ WIRE OVERHEAD CONSOLE POWER TAILGATE MODULE REAR VIEW CAMERA, TAILGATE HANDLE SWITCH RED WIRE WHT WIRE YEL WIRE

2.0L TURBO 2.4L ABS 1 FUSE BLK WIRE BRN WIRE C-CAN HI C-CAN LO E/R FUSE, RELAY BOX E/R JUNCTION BLOCK ESC MODULE ESC UNIT FORWARD COLLISION AVOIDANCE ASSIST MODULE FUEL PUMP CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START I/P-A LEFT BLIND-SPOT COLLISION WARNING UNIT MODULE 3 FUSE MULTI-PURPOSE CHECK CONNECTOR PASSENGER OCCUPANT DETECTION SENSOR PNK/BLK WIRE RED WIRE RIGHT BLIND-SPOT COLLISION WARNING UNIT SMART JUNCTION BLOCK SRS CONTROL MODULE W/ EPB WHT WIRE
