Rear wiper/washer circuit for Kia Sportage III (2010-2014)
Rear wiper/washer circuit
18 7 B-CAN LOW B-CAN HIGH
52 53 B-CAN LOW B-CAN HIGH
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
GRN/BLK WIRE
HOT IN ON
I/P JUNCTION BOX
I/P JUNCTION BOX (UNDER LEFT END OF DASH)
I/P-D
I/P-E
ICM RELAY BOX (CENTER OF DASH)
IPS CONTROL MODULE
MULTI- FUNCTION SWITCH
ON OFF INT
ORG/ WIRE
PARKING SWITCH
REAR WASHER MOTOR (BELOW RIGHT FRONT HEADLIGHT, IN WASHER RESERVOIR)
REAR WASHER SWITCH
REAR WIPER MOTOR (CENTER OF TAILGATE)
REAR WIPER RELAY
REAR WIPER RELAY CONTROL I/P-D
REAR WIPER SWITCH
RED WIRE
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIPER RR FUSE
WIPER SWITCH
