Front wiper/washer circuit for Kia Sportage III (2010-2014)
Front wiper/washer circuit
13 CHG-A
14 CHTG-BG WIPER P INPUT
2.0L
2.4L
21 17 5 16 INT (TIME) INT MIST WASHER SWITCH
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
COMPT)
DELAY CONTROL
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FRONT WASHER
FRONT WIPER (LOW) RELAY
FRONT WIPER (LOW) RELAY CONTROL
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
GRN WIRE
GRY WIRE
HI OFF LO INT
HOT IN ON
I/P JUNCTION BOX (UNDER LEFT END OF DASH)
I/P-C
I/P-E
LO INT HI OFF
LO INT OFF HI
MIST SWITCH
MOTOR (BELOW RIGHT FRONT HEADLIGHT, IN WASHER RESERVOIR)
MULTI- FUNCTION SWITCH
ORG/BLK WIRE
PARKING SWITCH
PCM (LEFT REAR OF ENGINE COMPT)
PNK WIRE
WASHER SWITCH
WHT/BLK WIRE
WIPER FRT FUSE
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
