2.0l, starting circuit, without smart key for Kia Sportage III (2010-2014)
2.0l, starting circuit, without smart key
BATTERY
BATTERY, BATTERY FUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
BURGLAR ALARM RELAY
CHTG-AG PCM (LEFT REAR OF ENGINE COMPT)
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT IN ON OR START
I/P JUNCTION BOX (UNDER LEFT END OF DASH)
I/P-B
I/P-E
IG 2 FUSE
IGNITION SWITCH
IPS CONTROL MODULE BURGLAR ALARM RELAY CONTROL
LOCK
MOTOR (LEFT REAR OF ENGINE)
ON/START IN
P/N SW
PNK WIRE
POSITION SWITCH CODE
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY
SIG (1)
SIG 2 SIG 3
SIG 4
SOLENOID
TCU 2 FUSE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
W/ BURGLAR ALARM
W/O BURGLAR ALARM
WHT WIRE
