Car Wiring Diagrams for 2.0l, starting circuit, with smart key for Kia Sportage III (2010-2014)

ANTI-THEFT SYSTEM BATTERY BATTERY, BATTERY FUSE BOX BLK WIRE BLU WIRE BRN WIRE E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT) EXTERIOR LIGHTS SYSTEM (LEFT SIDE OF DASH) FOB HOLDER B+ FOB-IN FUSE GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-B I/P-E IG 2 FUSE MOTOR (LEFT REAR OF ENGINE) ON/START IN ORG/BLK WIRE P/N SW (TOP OF TRANSAXLE) PDM (B+) FUSE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RELAY RELAY/ F/B ATM P/N SIGNAL RELAY SIG 1 SIG 2 SIG 3 SIG 4 SMART KEY SSB SSB STOP CONTROL MODULE LAMP (RIGHT SIDE SIGNAL OF DASH) SOLENOID START/STOP BUTTON SWITCH TCU 2 FUSE TRANSAXLE RANGE SWITCH WHT WIRE WHT/BLK WIRE
