Front heated seats circuit for Kia Sportage III (2010-2014)
Front heated seats circuit
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER FUSE
DRIVER GND IND LOW HIGH SEAT WARMER ECU
DRIVER SEAT WARMER RELAY
DRIVER SEAT WARMER SWITCH
GRY WIRE
GRY/ORG WIRE
HOT IN ON
HOT IN ON OR START
I/P JUNCTION BOX
I/P-F
ILL
LOW HIGH
MCU
NCA WIRE
NTC RECLINING WARMER CUSHION WARMER
ORG/ WIRE
PASSENGER GND IND LOW HIGH SEAT WARMER ECU
PASSENGER LOW SEAT WARMER RELAY HIGH
PASSENGER SEAT
RED WIRE
S/HEATER FRT FUSE
WARMER SWITCH
WHT WIRE
YEL WIRE
