Parking assistant circuit for Kia Sportage III (2010-2014)

Parking assistant circuit

Get access

B-CAN HI B-CAN LO BCM (CENTER OF DASH) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GND LIN GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-E ILL IND LEFT REAR CENTER PARKING ASSIST SENSOR (BEHIND LEFT SIDE OF REAR BUMPER) LEFT REAR PARKING ASSIST SENSOR (BEHIND LEFT SIDE OF REAR BUMPER) MODULE B+ FUSE MULTI SWITCH NCA WIRE ORG/ WIRE PWR PWR LIN REAR PARKING ASSIST BUZZER REAR PARKING ASSIST SENSOR REAR PARKING ASSIST SW IND REAR PARKING ASSIST SW SW REAR PARKING ASSIST SWITCH RED WIRE RED/ORG WIRE RIGHT REAR CENTER PARKING ASSIST SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER) RIGHT REAR PARKING ASSIST SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER) YEL WIRE
