Electronic power steering circuit for Kia Sportage III (2010-2014)

Electronic power steering circuit

Get access

1 2 GND BATT PWR 1 7 8 ON/START IN C-CAN HI C-CAN LO BLK WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM EPS CONTROL MODULE (STEERING COLUMN) EPS IND FUSE GRN WIRE GRY WIRE GRY/ORG WIRE HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-E I/P-F INSTRUMENT CLUSTER MCU MODULE ORG/ WIRE RED WIRE
