Car Wiring Diagrams for Defoggers circuit for Kia Sportage III (2010-2014)

13 32 (AUTO A/C) (MANUAL A/C) 24 21 (AUTO A/C) (MANUAL A/C) A/C CONTROL MODULE (LOWER CENTER OF DASH) B-CAN B-CAN HIGH LOW B-CAN HIGH B-CAN LOW BCM (CENTER OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BOX (LEFT SIDE OF ENGINE COMPT) BRN WIRE COMPUTER DATA LINES SYSTEM DEFOGGER DEFOGGER SWITCH DEICER FUSE DRIVER POWER OUTSIDE MIRROR E/R FUSE, RELAY FRONT WIPER DEICER (NEAR FRONT WIPER MOTOR) FRONT WIPER DEICER RELAY FRONT WIPER DEICER RELAY CONTROL GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES HTD MIRR FUSE I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-B I/P-C I/P-D I/P-E IND IPS CONTROL MODULE MANUAL AUTO A/C A/C NCA WIRE OFF PASSENGER POWER OUTSIDE MIRROR PNK WIRE REAR DEFOGGER REAR DEFOGGER RELAY REAR DEFOGGER RELAY CONTROL REAR DEFOGGER SWITCH INPUT RED WIRE RR HTD FUSE WHT/ORG WIRE
