Rear wiper/washer circuit for Kia Sportage II facelift (2008-2010)
Rear wiper/washer circuit
7 6 REAR WASHER IN REAR WIPER INT (TIME)
AUTO PARKING SWITCH (WIPERS AT REST)
BLK WIRE
BLU WIRE
BRN WIRE
CONTACT
DIODE 1
ETACM (UNDER CENTER CONSOLE)
FRONT WIPER/ WASHER CIRCUIT
GRN WIRE
HOT IN ON
I/P JUNCTION BOX
I/P-A
I/P-F
J/C
MULTI- FUNCTION SWITCH
NCA WIRE
ON OFF INT
ORG/ WIRE
ORG/BLK WIRE
REAR WASHER SWITCH
REAR WINDOW SWITCH
REAR WIPER MOTOR (BEHIND TRIM PANEL, IN TAILGATE)
REAR WIPER RELAY (BEHIND LEFT REAR QUARTERPANEL)
REAR WIPER RLY CTRL
REAR WIPER SWITCH
RED WIRE
RR WIPER FUSE
TAIL GATE SAFETY RELAY
TAIL GATE SWITCH
WASHER MOTOR (BELOW RIGHT FRONT HEADLIGHT, IN WASHER RESERVOIR)
WHT WIRE
