2.0l, a/t circuit for Kia Sportage II facelift (2008-2010)

ATM FUSE ATM RELAY ATM SOLENOID VALVE (TOP OF TRANSAXLE) AUTO CRUISE BLK WIRE BLK/ORG WIRE BLU WIRE CRUISE CONTROL MODULE (ON RIGHT FENDER, BEHIND STRUT TOWER) DCC ATM RLY 'ON' IN DOWN SHIFT N INPUT E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPARTMENT) ECU FUSE GRN/ORG WIRE GROUND 38 39 40 LR GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-E JOINT CONNECTOR O/T OIL TEMP SENSOR ORG/ WIRE PNK ATM RELAY CTRL OD WIRE PNK PNK PNK WIRE PNK WIRE PULSE GEN A D INPUT PULSE GENERATOR "A" (ON TOP OF TRANSAXLE) PULSE GENERATOR ``B" (TOP RIGHT REAR OF ENGINE) PWM SIGNAL RED WIRE RED/BLK WIRE SENSOR GND STOPLAMP SW PULSE GEN B SELECT SW P INPUT TRANSMISSION CONTROL MODULE (TCM) (UNDER LEFT SIDE OF DASH) UP SHIFT R INPUT WHT WIRE WHT/BLK WIRE YEL WIRE YEL/ORG WIRE

ATM LEVER SWITCH (AT BASE OF GEAR SELECTOR ASSEMBLY) B/UP FUSE BLK WIRE BLU WIRE CLUSTER FUSE COMPARTMENT) DOWN SHIFT E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-A I/P-C I/P-D I/P-G ILL INSTRUMENT CLUSTER JOINT CONNECTOR MANUAL MCU PNK WIRE POWER PWM SIG RED WIRE RED/BLK WIRE RED/ORG WIRE SELECT SWITCH NORMAL STARTING/ CHARGING SYSTEM STOP FUSE STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) SWITCH (ON TOP LEFT SIDE OF TRANSAXLE) TRANSAXLE RANGE UP SHIFT WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE
