Back-up lamps circuit for Kia Sportage II facelift (2008-2010)

Back-up lamps circuit

Get access

2.0L 2.7L A/T B/UP FUSE BACK UP LAMP BACK-UP LAMP SWITCH (TOP OF TRANSAXLE) BLK WIRE BLU WIRE ENGINE ROOM JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT) GRN WIRE HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-A JOINT I/P-G I/P JUNCTION BOX 10 I/P-F (UNDER LEFT END OF DASH) LEFT REAR COMBINATION LAMP NCA WIRE PNK WIRE REAR PARKING ASSIST CONTROL MODULE (2009) (LATE PRODUCTION) RIGHT REAR COMBINATION LAMP TCM (UNDER LEFT SIDE OF DASH) TRANSAXLE RANGE SWITCH (ON TOP LEFT SIDE OF TRANSAXLE) WHT WIRE
