Cooling fan circuit for Kia Sportage II facelift (2008-2010)
Cooling fan circuit
31 73 25 24 ECT SENS ECT SENS
50 50 (2.0L) (2.7L)
64 65 40 18 FAN (HIGH) CTRL FAN (LOW) CTRL
BLK WIRE
BLK/ORG WIRE
BLU WIRE
COOLING FAN 2 FUSIBLE LINK
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN RELAY 1 (HIGH)
COOLING FAN RELAY 2 (LOW)
E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT)
ECM (UNDER LEFT SIDE OF DASH)
ECM FUSE
ENGINE COOLANT TEMPERATURE SENSOR, SENDER (TOP LEFT REAR OF ENGINE)
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES COOLING FAN 1 FUSIBLE LINK
MAIN RELAY
NCA WIRE
RED WIRE
WHT WIRE
YEL WIRE
