2.0l, immobilizer circuit for Kia Sportage II facelift (2008-2010)
2.0l, immobilizer circuit
ANT
ANT COIL
BLK WIRE
BLU/BLK WIRE
E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT)
ECM (UNDER LEFT SIDE OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
I/P JUNCTION BOX (UNDER LEFT END OF DASH)
I/P-E
IMMO GND
IMMO IND
IMMOBILIZER IND
INSTRUMENT CLUSTER
KEY REMIND SWITCH (TOP RIGHT SIDE OF STEERING COLUMN)
NCA WIRE
ORG/ WIRE
PNK MEMORY PWR WIRE
PNK WIRE
RED WIRE
ROOM LP FUSE
SIG
SMATRA
SMATRA (SMART TRANSPONDER ANTENNA) (UNDER LEFT SIDE OF DASH)
SNSR FUSE
WHT/BLK WIRE
