Tire pressure monitoring circuit for Kia Sportage II (2004-2008)

Tire pressure monitoring circuit

Get access

BLK WIRE BRN/BLK WIRE CLUSTER FUSE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-C I/P-E INSTRUMENT CLUSTER JOINT CONNECTOR JOINT CONNECTOR ORG/ WIRE PNK VEHICLE SPEED SENSOR WIRE PNK WIRE RED WIRE ROOM LP FUSE TIRE PRESSURE MONITORING MODULE (UNDER LEFT SIDE OF DASH) TPMS IND WHT WIRE
