Headlamps circuit, without drl for Kia Sportage II (2004-2008)
Headlamps circuit, without drl
11 11 (2.0L) (2.7L)
32 32 (2.0L) (2.7L)
54 54 1 1 (2.0L) (2.7L)
BLK WIRE
BLU WIRE
DIMMER, PASSING SWITCH
E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT)
ETACM (UNDER CENTER CONSOLE)
FOG LAMP SWITCH
FRONT FOG LAMP RELAY
GRN WIRE
H/LP (HIGH) FUSE
H/LP (LOW) FUSE
HEAD- LAMP RELAY (HIGH)
HEAD- LAMP RELAY (LOW)
HIGH BEAM
HOT AT ALL TIMES
HOT IN ON I/P JUNCTION BOX FUSE IGN (UNDER LEFT END OF DASH)
I/P-D
I/P-G
IND
INSTRUMENT CLUSTER FOG LAMP
J/C
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HEAD- LAMP
LIGHT SWITCH
LO HI
LOW FLASH HIGH
LOW LOW
MULTI- FUNCTION SWITCH
ORG/ WIRE
PARK HEAD OFF
PNK WIRE
RED WIRE
RIGHT HEAD- LAMP
WHT WIRE
