Car Wiring Diagrams for Ground distribution circuit for Kia Sportage II (2004-2008)

A/C CONTROL MODULE ABS CONTROL MODULE ABS CONTROL MODULE ESP CONTROL MODULE ABS/ TCS AUDIO AUTO LIGHT, PHOTO SENSOR AUTO- MATIC A/C BLK WIRE COOLING FAN MOTOR BLOWER RELAY DIGITAL CLOCK DRIVER SEAT BUCKLE SWITCH ELECTRO- CHROMIC MIRROR ESP ABS/ TCS ESP ETACM FLASHER UNIT FUEL SENDER, FUEL PUMP MOTOR GLOVE BOX LAMP CIGARETTE LIGHTER I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-D I/P-H ICM BOX INSTRUMENT CLUSTER JOINT CONNECTOR LEFT SIDE REPEATER LAMP LOCK SWITCH MANUAL A/C AUTOMATIC A/C MAP LAMP ROOM LAMP MODE SWITCH MULTI- FUNCTION SWITCH PASSENGER SEAT BUCKLE SWITCH POWER MOSFET RHEOSTAT SUNROOF CONTROLLER CARGO LAMP SUNROOF SWITCH TIRE PRESSURE MONITORING MODULE WASHER LEVEL SWITCH

1 2 (M/T) (A/T) 2.0L AQS SENSOR ATM RELAY ECM BLK WIRE BRAKE FLUID LEVEL SENSOR CRUISE CLUTCH PEDAL POSITION SWITCH CRUISE CONTROL MODULE DATA LINK CONNECTOR DRL CONTROL MODULE E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT) ECM, TCM FRONT WIPER MOTOR WINDSHIELD DEFOGGER JOINT CONNECTOR KNOCK SENSOR SHIELD LEFT FRONT FOG LAMP LEFT FRONT POWER WINDOW SWITCH LEFT HEADLAMP LEFT HORN LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW SWITCH LEFT DOOR KEY SWITCH LEFT SEAT WARMER MASS AIR FLOW SENSOR MULTI- FUNCTION SWITCH MULTIPURPOSE CHECK CONNECTOR ORG/ WIRE RELAY RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT FOG LAMP RIGHT FRONT POWER WINDOW SWITCH RIGHT HEADLAMP RIGHT HORN RIGHT SIDE REPEATER LAMP SIREN SUB-WOOFER VEHICLE SPEED SENSOR WASHER MOTOR

ATM RELAY BLK WIRE BRAKE FLUID LEVEL SENSOR CONTACT CRUISE CONTROL MODULE DATA LINK CONNECTOR DRL CONTROL MODULE E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT) FRONT POWER OUTLET FRONT WIPER MOTOR FUEL SENDER, FUEL PUMP MOTOR HIGH MOUNTED STOP LAMP IGNITION COIL SHIELD JOINT CONNECTOR MAF SENSOR SHIELD ECM MULTI- FUNCTION SWITCH MULTIPURPOSE CHECK CONNECTOR OCS MODULE AMPLIFIER 1 ORG/ WIRE REAR POWER OUTLET REAR WINDOW SWITCH REAR WIPER RELAY LEFT REAR COMBINATION LAMP RIGHT DOOR KEY SWITCH LEFT SEAT WARMER RIGHT POWER OUTSIDE MIRROR MOTOR RIGHT REAR COMBINATION LAMP RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR POWER WINDOW SWITCH SIREN SRS CONTROL MODULE TAIL GATE KEY SWITCH RIGHT LICENSE LAMP LEFT LICENSE LAMP TAIL GATE LOCK ACTUATOR TCM TELLTALE LAMP TRAILER POWER OUTLET VEHICLE SPEED SENSOR WINDSHIELD DEFOGGER
