2.7l, computer data lines circuit for Kia Sportage II (2004-2008)

2.7l, computer data lines circuit (1 of 2)

Sportage Kia II (2004-2008): 2.7l, computer data lines circuit (1 of 2)

Get access

7 6 K-LINE ECM,TCM ABS CONTROL MODULE (IN RIGHT FRONT CORNER OF ENGINE COMPARTMENT) ABS/ TCS AUTO TRANSAXLE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ESP ESP CONTROL MODULE FUSE OBD II GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-B I/P-C I/P-D IMMOBILIZER CONTROL MODULE (UNDER LEFT SIDE OF DASH) J/C MODULE (UNDER LEFT SIDE OF DASH) ORG/ WIRE SRS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) TCM (UNDER LEFT SIDE OF DASH) TIRE PRESSURE MONITORING VERTICAL RESISTOR (UNDER LEFT END OF DASH) W/ AUTO TRANSAXLE W/ IMMOBILIZER W/O IMMOBILIZER WHT WIRE YEL/ORG WIRE

2.7l, computer data lines circuit (2 of 2)

Sportage Kia II (2004-2008): 2.7l, computer data lines circuit (2 of 2)

Get access

BLK WIRE BLU/ORG WIRE BRN/BLK WIRE BRN/ORG WIRE E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT) GRN/BLK WIRE GRN/ORG WIRE J/C MULTIPURPOSE CHECK CONNECTOR (LEFT REAR CORNER OF ENGINE COMPARTMENT) TCM (UNDER LEFT SIDE OF DASH) VEHICLE SPEED SENSOR (A/T) (TOP OF TRANSAXLE) WHT WIRE YEL/ORG WIRE
