Car Wiring Diagrams for 2.0l, computer data lines circuit for Kia Sportage II (2004-2008)

ABS CONTROL MODULE (IN RIGHT FRONT CORNER OF ENGINE COMPARTMENT) ABS/ TCS BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ECM (UNDER LEFT SIDE OF DASH) ESP ESP CONTROL MODULE FUSE OBD II GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES I/P JUNCTION BOX (UNDER LEFT END OF DASH) I/P-B I/P-C I/P-D J/C ORG/ WIRE SRS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) TIRE PRESSURE MONITORING MODULE (UNDER LEFT SIDE OF DASH) VERTICAL RESISTOR (UNDER LEFT END OF DASH) WHT WIRE YEL/ORG WIRE

A/T BLK WIRE BLU/ORG WIRE BRN/BLK WIRE BRN/ORG WIRE E/R JUNCTION BOX GRN/ORG WIRE J/C M/T MULTIPURPOSE CHECK CONNECTOR (LEFT REAR CORNER OF ENGINE COMPT) VEHICLE SPEED SENSOR (TOP OF TRANSAXLE) WHT WIRE YEL/ORG WIRE
