Kia Sportage II (2004-2008) rf whl spd lf whl spd lr whl spd rr whl spd Wiring diagram
This page shows the only wiring diagram for the component.rf whl spd lf whl spd lr whl spd rr whl spd, which is found in the car Kia Sportage II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf whl spd lf whl spd lr whl spd rr whl spd (1 of 1)
1 2 3 4 5 MEMORY PWR
2.0L 2.7L
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (2.7L) (BEHIND CENTER OF DASH)
E/R JUNCTION BOX (IN LEFT FRONT FUSE CORNER OF ENGINE COMPARTMENT)
ECU FUSE
ELECTRONIC MAGNETIC VALVE CLUTCH (NEAR FUEL TANK)
EMC +
GRN WIRE
GROUND CAN LOW CAN HIGH
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P JUNCTION BOX (UNDER LEFT END OF DASH)
I/P-C
I/P-E
ILL
IND
INSTRUMENT CLUSTER
JOINT CONNECTOR
LEFT FRONT WHEEL SENSOR (ON LEFT FRONT HUB ASSEMBLY)
LEFT REAR WHEEL SENSOR (ON LEFT REAR HUB ASSEMBLY)
LOCK IND
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/ORG WIRE
RF WHL SPD LF WHL SPD LR WHL SPD RR WHL SPD
RIGHT FRONT WHEEL SENSOR (ON RIGHT FRONT HUB ASSEMBLY)
RIGHT REAR WHEEL SENSOR (ON RIGHT REAR HUB ASSEMBLY)
SAS 1 SAS 2
SAS C SAS GROUND EMC - K-LINE ON/START
STEERING ANGLE SENSOR
SWITCH
WHT WIRE
YEL WIRE
Go to component -> 4wd circuit -> RF WHL SPD LF WHL SPD LR WHL SPD RR WHL SPD
