Kia Sportage II (2004-2008) engg running input sig defog rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.engg running input sig defog rly ctrl, which is found in the car Kia Sportage II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engg running input sig defog rly ctrl (1 of 1)
2.0L 2.7L
A/C CONTROL MODULE (BEHIND CENTER OF CONSOLE, FORWARD OF SHIFT LEVER)
AUTOMATIC A/C MANUAL A/C
BLK WIRE
DEFOG SW
E/R JUNCTION BOX (IN LEFT FRONT CORNER OF ENGINE COMPT)
ENGG RUNNING INPUT SIG DEFOG RLY CTRL
ETACM (UNDER CENTER CONSOLE)
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
ORG/ WIRE
STARTING/ CHARGING SYSTEM
W/DEF FUSE
WHT WIRE
WINDSHIELD DEFOGGER
WINDSHIELD DEFOGGER RELAY
Go to component -> Front defogger circuit -> ENGG RUNNING INPUT SIG DEFOG RLY CTRL
