Kia Spectra II (2004-2008) rear defo- gger switch Wiring diagram
This page shows the only wiring diagram for the component.rear defo- gger switch, which is found in the car Kia Spectra II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defo- gger switch (1 of 1)
4 DOOR
5 DOOR
BCM
BLK WIRE
BLU WIRE
DEFOGGER
ENGINE ROOM JUNCTION BOX (LEFT REAR OF ENGINE COMPT)
GGER
GLASS ANTENNA
HOT AT ALL TIMES
HTD/MIRR FUSE
I/P-B
I/P-F
INSTRUMENT CLUSTER DEFOGGER IND
INSTRUMENT PANEL JUNCTION BOX
IP B+ FUSE
JE-04
LEFT OUTSIDE MIRROR MOTOR, DEFOGGER (FRONT OF LEFT FRONT DOOR)
NCA WIRE
ORG/ WIRE
PNK WIRE
REAR DEFO- GGER SWITCH
REAR DEFOGGER RELAY
REAR WINDOW DEFO-
REAR WINDOW DEFOGGER
RED WIRE
RIGHT OUTSIDE MIRROR MOTOR, DEFOGGER (FRONT OF RIGHT FRONT DOOR)
RR/HTR FUSE
W/ GLASS ANTENNA W/O GLASS ANTENNA
WAVETRAP
