Kia Spectra II (2004-2008) electronic chrome mirror instrument cluster Wiring diagram
This page shows the only wiring diagram for the component.electronic chrome mirror instrument cluster, which is found in the car Kia Spectra II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic chrome mirror instrument cluster (1 of 1)
A/C CONTROL MODULE
AUTO LIGHT CONTROL MODULE
BCM
BLK BLK WIRE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CIGARETTE LIGHTER
CONDENSER FAN 2 RELAY
CONDENSER FAN MOTOR
DATA LINK CONNECTOR
DIGITAL CLOCK
ELECTRONIC CHROME MIRROR INSTRUMENT CLUSTER
FUEL SENDER, FUEL PUMP MOTOR
GLOVE BOX ILL RHEOSTAT
HAZARD SWITCH BCM AUDIO
I/P JUCTION BOX
I/P-A
INSTRUMENT CLUSTER
JE-01
KNOCK SENSOR SHIELD
LEFT FRONT SEAT WARMER SWITCH RIGHT FRONT SEAT WARMER SWITCH
LEFT HEAD LAMP CENTER HORN
LEFT HORN
MULTI- FUNCTION SWITCH
MULTI-FUNCTION SWITCH SUNROOF MOTOR
NCA WIRE
ORG/ WIRE
PCM
POWER OUTLET
POWER SOCKET RELAY
REAR DEFOGGER SWITCH TRUNK LID SWITCH
RELAY
REMOTE KEYLESS INSTRUMENT CLUSTER
RIGHT HEADLIGHT
ROOM LAMP
SUNROOF SWITCH
TCM
Go to component: -> Ground distribution circuit (2 of 2) -> ELECTRONIC CHROME MIRROR INSTRUMENT CLUSTER
