Car Wiring Diagrams for Radio circuits for Kia Spectra I facelift (2001-2004)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 IGN B+ PNK WIRE BLK WIRE BLU/WHT WIRE BRN/BLK WIRE BRN/GRN WIRE ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE BOX (BEHIND LEFT KICK PANEL) AUDIO FUSE GND ILLUM GRN WIRE HOT AT ALL TIMES HOT IN ACC OR RUN J/C 11 JB-01 LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER LEFT TWEETER SPEAKER LT GRN/YEL WIRE ORG/BLK WIRE PNK WIRE RADIO RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER RIGHT TWEETER SPEAKER ROOM FUSE SC-06 SC-08 WHT/BLK WIRE WHT/GRN WIRE X-17 YEL/RED WIRE YEL/WHT WIRE
