Car Wiring Diagrams for Headlight circuit, with drl for Kia Spectra I facelift (2001-2004)

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-01 C-01 INSTRUMENT CLUSTER E-01 E-01 COMBINATION SWITCH ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT REAR SIDE OF ENGINE COMPARTMENT) ENGINE COMPT FUSE/ REALY BOX (AT LEFT REAR SIDE OF ENGINE COMPT) ETWIS (BEHIND LEFT KICK PANEL) FOG FUSE FRONT FOG LAMP RELAY FRONT FOG LAMP SWITCH GRN WIRE HEAD FUSE HEAD HI FUSE HEAD LOW FUSE HEADLIGHT RELAY HEADLIGHT RELAY 2 HI BEAM INDIC- ATOR HOT AT ALL TIMES HOT IN ON OR ACC JB-01 JB-02 JB-06 JOINT CONNECTOR 10 JOINT CONNECTOR 2 JOINT CONNECTOR JC-02 LEFT FOG LAMP LEFT HEADLIGHT LO HI PASS OFF HEAD PNK WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FOG LAMP RIGHT HEADLIGHT TNS TNS FUSE TNS OFF HEAD TNS RELAY WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/WHT WIRE BRN/WHT WIRE DRL RELAY (BEHIND LEFT SIDE OF DASH) DRL UNIT (BEHIND LEFT SIDE OF DASH) ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT) FUSE BOX (BEHIND LEFT KICK PANEL) GRN WIRE HEAD FUSE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR) INSTRUMENT CLUSTER SYSTEM (CHARGE INDICATOR) JB-01 JOINT CONNECTOR 1 PARKING BRAKE SWITCH PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE SR/ACC FUSE TCU IG FUSE VIO WIRE VIO/WHT WIRE WHT WIRE X-17 YEL WIRE YEL/RED WIRE
