Back-up lamps circuit, 4 door for Kia Spectra I facelift (2001-2004)
Back-up lamps circuit, 4 door
A/T
BACK-UP
BACK-UP LIGHT SWITCH (ON LOWER LEFT SIDE OF TRANSAXLE CASE)
BLK WIRE
BLU/BLK WIRE
FUSE BOX (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
LEFT REAR COMBINATION LIGHTS
M/T
METER FUSE
RED/YEL WIRE
RIGHT REAR COMBINATION LIGHTS
S/C-07 (BEHIND LEFT KICK PANEL)
SC-06 (BEHIND LEFT KICK PANEL)
TRANSAXLE RANGE SWITCH (ON TOP LEFT OF TRANSAXLE)
X-17
YEL WIRE
