Kia Spectra I facelift (2001-2004) speedometer assembly wiring diagram
This page shows the only wiring diagram for the component.speedometer assembly, which is found in the car Kia Spectra I facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
speedometer assembly wiring diagram (1 of 1)
A/T
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH SWITCH (ABOVE CLUTCH PEDAL)
CRUISE CONTROL (ACC) INDICATOR
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MODULE (RIGHT REAR OF ENGINE COMPARTMENT)
CRUISE CONTROL SWITCH
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH, MOUNTED TO FLOOR)
FUSE
FUSE BOX (LEFT KICK PANEL
GRN WIRE
HOT AT ALL TIMES
HOT IN
HOT IN ON
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C 11
JB-01
JC-01
JC-02
M/T
METER FUSE
OFF
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RESUME/ ACCEL
SC-06 (LEFT KICK PANEL)
SC-08 (LEFT SIDE OF DASH)
SC-11 (LEFT KICK PANEL)
SET/ COAST
SPEEDOMETER ASSEMBLY
STARTER FUSE
STOP FUSE
STOP- LIGHT SWITCH (ABOVE BRAKE PEDAL)
TRANSAXLE CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VSS INPUT
WHT WIRE
X-17
YEL WIRE
Go to component -> Cruise control circuit -> SPEEDOMETER ASSEMBLY
