Kia Spectra I facelift (2001-2004) sens down fuse Wiring diagram

A/C SYSTEM BLK WIRE BLK/GRN WIRE BLK/LT GRN WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CONDENSER PNK PNK 1 2 3 4 WIRE CRANKSHAFT POSITION SENSOR ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT) ENGINE CONTROL MODULE (BEHIND LOWER CENTER OF DASH) FUEL INJECTORS FUEL PUMP (IN FUEL TANK) FUEL PUMP FUSE FUEL PUMP RELAY GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON, START HOT IN START IG-COIL FUSE IGNITION COILS INJ FUSE JB-01 JB-02 JB-05 LT GRN/YEL WIRE M/T A/T MAIN RELAY ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PURGE SOLENOID VALVE (CENTER REAR OF ENGINE COMPT) RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SENS DOWN FUSE SENS UP FUSE SHORT CONNECTOR JC-08 (BELOW CENTER OF DASH) SPARK PLUGS STARTER FUSE VIO/WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
