Kia Spectra I facelift (2001-2004) right front combination lights left headlight Wiring diagram
This page shows the only wiring diagram for the component.right front combination lights left headlight, which is found in the car Kia Spectra I facelift (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front combination lights left headlight (1 of 1)
A/T
AIR BAG CONTROL UNIT
AIR QUALITY SENSOR
ANTI-LOCK BRAKE CONTROL UNIT
BATTERY
BLK WIRE
CAMSHAFT POSITION SENSOR
CHECK CONNECTOR (PARTIAL)
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
COOLING FAN MOTOR
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR (DLC) (PARTIAL)
ENGINE CONTROL MODULE (ECM)
FRONT FOG LAMP RELAY
GROUND
HORN
JB-01 ENGINE COMPARTMENT FUSE/RELAY BOX
JB-05
JOINT CONNECTOR JC-8
KNOCK SENSOR SHIELD
LEFT FRONT COMBINATION LIGHTS
LEFT FRONT FOG LAMP
LEFT HEADLIGHT
LEFT REAR POWER WINDOW SWITCH
LT GRN WIRE
M/T
NCA WIRE
RED WIRE
RIGHT FRONT COMBINATION LIGHTS LEFT HEADLIGHT
RIGHT FRONT FOG LAMP
RIGHT HEADLIGHT
SEAT BELT SWITCH
SHORT CONNECTOR SC-02
TRANSAXLE CONTROL MODULE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 2) -> RIGHT FRONT COMBINATION LIGHTS LEFT HEADLIGHT
