Kia Spectra I facelift 2 (2004-2011) trunk lid open relay Wiring diagram
This page shows the only wiring diagram for the component.trunk lid open relay, which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid open relay (1 of 1)
A/CON FUSE
A/CON RELAY
ABS 1 FUSIBLE LINK
ABS 2 FUSIBLE LINK
ABS CONTROL MODULE
ALT FUSIBLE LINK
BATTERY
BLK WIRE
BLOWER FUSIBLE LINK
BLOWER RELAY
BLU WIRE
CANISTER CLOSE VALVE
CBG-K
COND FUSIBLE LINK
CONDENSER FAN 1 RELAY
CONDENSER FAN 2 RELAY
DRL RELAY
E/R-CBG
E/R-CBG 13
E/R-FRT
ECM IMMOBILIZER CONTROL MODULE
ECU 2 FUSE
F/PUMP FUSE
F/WIPER FUSE
FRONT FOG LAMP RELAY
FRONT WIPER MOTOR
FRONT WIPER RELAY
FUEL PUMP RELAY
GENERATOR
GRN WIRE
HDLP HI FUSE
HDLP LO FUSE
HIGH HEADLAMP RELAY
HORN FUSE
HORN RELAY
IDLE SPEED ACTUATOR
IGN 1 FUSIBLE LINK
IGN 2 FUSIBLE LINK
IGNITION COIL
INJ FUSE
INJECTOR 2
INJECTOR 3 CAMSHAFT INJECTOR 4 POSITION SENSOR
IP B+ FUSIBLE LINK
LOW HEADLAMP RELAY
MAIN RELAY
MASS AIR CRANKSHAFT FLOW POSITION SENSOR SENSOR
MOTOR
MULTI- FUNCTION SWITCH
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
OIL CONTROL VALVE
OXYGEN OXYGEN SENSOR SENSOR (UP) (DOWN)
PNK WIRE
PNK/BLK WIRE
PURGE INJECTOR 1 CONTROL SOLENOID VALVE
RAD FUSIBLE LINK
RADIATOR FAN RELAY
RED WIRE
RED/ORG WIRE
RED/YEL WIRE
RELAY
SNSR FUSE
STOP FUSE
STOP LAMP SWITCH
T/OPEN FUSE
TO INSTRUMENT PANEL (I/P) JUNCTION BOX (DIAGRAM 3 OF 4)
TRUNK LID OPEN RELAY
W/ CRUISE W/O CRUISE
W/ DRL
WHT WIRE
Go to component -> Power distribution circuit (1 of 4) -> TRUNK LID OPEN RELAY
