Kia Spectra I facelift 2 (2004-2011) rear wiper relay i/p-d 12 i/p-b rear wiper washer Wiring diagram
This page shows the only wiring diagram for the component.rear wiper relay i/p-d 12 i/p-b rear wiper washer, which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear wiper relay i/p-d 12 i/p-b rear wiper washer (1 of 1)
BCM (INTEGRAL TO INSTRUMENT PANEL (I/P) JUNCTION BOX)
BLK WIRE
BLK/RED WIRE
BLU WIRE
FRONT WASHER MOTOR (ON WASHER FLUID RESERVOIR)
FRONT WIPER/WASHER CIRCUIT
HOT IN ON
I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH,
I/P-F
MULTI- FUNCTION SWITCH
ON OFF
ORG/ WIRE
REAR WASHER SWITCH
REAR WIPER MOTOR (CENTER REAR OF TAILGATE)
REAR WIPER RELAY I/P-D 12 I/P-B REAR WIPER WASHER
REAR WIPER SWITCH INT
RED/YEL WIRE
SWITCH
WHT WIRE
WHT/ORG WIRE
WIPER INT SWITCH I/P-A
YEL/BLK WIRE
Go to component -> Rear wiper/washer circuit, 5 door -> REAR WIPER RELAY I/P-D 12 I/P-B REAR WIPER WASHER
