Kia Spectra I facelift 2 (2004-2011) passenger tweeter speaker Wiring diagram
This page shows the only wiring diagram for the component.passenger tweeter speaker, which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger tweeter speaker (1 of 1)
4 DOOR
5 DOOR
ANTENNA GROUND
AUDIO
AUX GND AUX INL
AUX IN AUX INL
AUX IN AUX INR
AUX JACK
AUX-GROUND
BLK WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
CIRCUIT
DRIVER DOOR SPEAKER
DRIVER TWEETER SPEAKER
F/CABLE
FEEDER CABLE
FM AM
GLASS ANTENNA (IF EQUIPPED)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH) AUDIO FUSE
ILL (-) ILL (+) AUX INR GROUND
LEFT REAR SPEAKER
NCA WIRE
PASSENGER DOOR SPEAKER
PASSENGER TWEETER SPEAKER
PNK WIRE
POWER CONNECTOR ROOM FUSE
RIGHT REAR SPEAKER
ROOF ANTENNA
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuit -> PASSENGER TWEETER SPEAKER
