Kia Spectra I facelift 2 (2004-2011) passenger outside mirror defogger passenger door) wiring diagram
This page shows the only wiring diagram for the component.passenger outside mirror defogger passenger door), which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger outside mirror defogger passenger door) wiring diagram (1 of 1)
AUDIO FUSE
BLK WIRE
DEFOGGER SYSTEM
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
I/P JUNCTION BOX (UNDER LEFT SIDE OF DASH,
I/P-F
LEFT
LEFT RIGHT
LEFT RIGHT LEFT
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE MIRROR DEFOGGER PASSENGER DOOR)
PASSENGER POWER OUTSIDE MIRROR MOTOR (FRONT OF
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED/WHT WIRE
RIGHT
SELECTOR RIGHT SWITCH
UP/ DOWN DOWN UP UP DOWN
UP/DOWN LEFT/RIGHT
YEL WIRE
Go to component -> Power mirror circuit -> PASSENGER OUTSIDE MIRROR DEFOGGER PASSENGER DOOR)
