Kia Spectra I facelift 2 (2004-2011) defogger defogger switch relay i/p-b Wiring diagram
This page shows the only wiring diagram for the component.defogger defogger switch relay i/p-b, which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defogger defogger switch relay i/p-b (1 of 1)
4 DOOR
5 DOOR
A/C CONTROL MODULE
BCM
BLK WIRE
DEFOGGER
DEFOGGER DEFOGGER SWITCH RELAY I/P-B
DEFOGGER SWITCH
DRIVER POWER OUTSIDE MIRROR MOTOR (FRONT OF LEFT FRONT DOOR)
ENGINE ROOM JUNCTION BOX (LEFT REAR OF ENGINE COMPT)
GLASS ANTENNA
HOT AT ALL TIMES IP B+ FUSIBLE LINK
HTD/MIRR FUSE
I/P-F
I/P-F PNK WIRE
INSTRUMENT PANEL JUNCTION BOX
LATE PRODUCTION EARLY PRODUCTION
NCA WIRE
PASSENGER POWER OUTSIDE MIRROR MOTOR
PNK WIRE
REAR DEFOGGER
REAR DEFOGGER REAR WINDOW DEFOGGER
REAR DEFOGGER RELAY
RED WIRE
RR/HTR FUSE
W/ W/O GLASS GLASS ANTENNA ANTENNA
Go to component -> Defoggers circuit -> DEFOGGER DEFOGGER SWITCH RELAY I/P-B
