Kia Spectra I facelift 2 (2004-2011) blower a/c control relay module Wiring diagram
This page shows the only wiring diagram for the component.blower a/c control relay module, which is found in the car Kia Spectra I facelift 2 (2004-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blower a/c control relay module (1 of 1)
A/CON FUSE
A/T
AUDIO
BCM
BLK WIRE
BLOWER A/C CONTROL RELAY MODULE
BLU WIRE
BRN/BLK WIRE
DATA LINK A/C DOOR CONNECTOR CONTROL WARNING MODULE SWITCH
DIGITAL CLOCK, TELLTALE
E/R-CBG
ENGINE ROOM (E/R) JUNCTION BOX (LEFT REAR OF ENGINE COMPT)
FROM ENGINE ROOM (E/R) JUNCTION BOX (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FRONT FOG LAMP RELAY
FUSE
GRN/BLK WIRE
HIGH HEADLAMP RELAY
I/P-F
IGN FUSE
INSTRUMENT PANEL (I/P) JUNCTION BOX (UNDER LEFT
INSTRUMENT PANEL (I/P) JUNCTION BOX (UNDER LEFT SIDE OF DASH)
INSTRUMENT TIRE CLUSTER PRESSURE MONITORING MODULE
KEYLESS IGNITION ENTRY LOCK RECEIVER SWITCH
LOW HEADLAMP RELAY
LUGGAGE LAMP
M/T
MAP ROOM LAMP LAMP (W/O OVERHEAD CONSOLE)
MULTI- FUNCTION SWITCH
ON IN
ORG/ WIRE
PNK WIRE
POWER CONNECTOR ROOM FUSE
PWR BATT
REAR REAR WIPER WIPER RELAY MOTOR
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RED/YEL WIRE
RKE FUSE
SIDE OF DASH)
STARTER RELAY
SUNROOF MOTOR
SUNROOF SWITCH (W/ OVERHEAD CONSOLE)
TO POWER WINDOW RELAY (DIAGRAM 4 OF 4)
TRANSAXLE RANGE SWITCH
W/O W/ IGNITION IGNITION LOCK LOCK
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> BLOWER A/C CONTROL RELAY MODULE
