Kia Spectra I facelift 2 (2004-2011) 1 2 3 4 batt pwr rke signal ground Wiring diagrams

1 2 3 4 BATT PWR RKE SIGNAL GROUND ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE COMPUTER DATA LINES SYSTEM DOOR LOCK RELAY DOOR LOCK RELAY CONTROL DOOR LOCK SW IN DOOR LOCK SWITCH DOOR OPEN IND DOOR OPEN IND OUT DOOR UNLOCK RELAY DOOR UNLOCK RELAY CONTROL DOOR UNLOCK SW IN DOOR WARNING SWITCH DR DOOR KEY UNLCK SW DR/PASS DOOR LOCK DRIVER DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR) DRIVER DOOR SWITCH (IN LEFT "B" PILLAR) GRN (OR BLU) WIRE GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES I/P-A I/P-B I/P-C I/P-D I/P-E I/P-F INSTRUMENT CLUSTER INSTRUMENT PANEL JUNCTION BOX (UNDER LEFT SIDE OF DASH) KEY REMIND SW KEYLESS ENTRY RECEIVER (IF EQUIPPED) (UNDER GLOVE COMPARTMENT) LEFT REAR DOOR LOCK ACTUATOR (IN RIGHT (AT REAR "B" PILLAR) OF LEFT REAR DOOR) LOCK SWITCH MUX ORG/ WIRE ORG/BLK WIRE PASS DOOR UNLCK SW PASSENGER DOOR SWITCH (IN RIGHT "B" PILLAR) PASSENGER POWER WINDOW, POWER DOOR PNK (OR BLU) WIRE PNK (OR GRN) WIRE PNK PNK 1 2 WIRE PNK WIRE POWER CONNECTOR POWER WINDOW MAIN SWITCH REAR DOOR LOCK RED WIRE RED/BLK WIRE RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) RKE FUSE BCM ROOM FUSE SRF/D LOCK FUSE TAILGATE LOCK ACTUATOR (5 DOOR) (CENTER REAR OF TAILGATE) TWO TURN UNLOCK RELAY TWO TURN UNLOCK RELAY CONTROL W/ BURGLAR ALARM W/O BURGLAR ALARM WHT WIRE YEL/BLK WIRE YEL/ORG WIRE

1 2 3 4 BATT PWR RKE SIGNAL GROUND ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE COMPUTER DATA LINES SYSTEM DOOR LOCK RELAY DOOR LOCK RELAY CONTROL DOOR LOCK SW IN DOOR LOCK SWITCH DOOR OPEN IND DOOR OPEN IND OUT DOOR UNLOCK RELAY DOOR UNLOCK RELAY CONTROL DOOR UNLOCK SW IN DOOR WARNING SWITCH DR DOOR KEY UNLCK SW DR/PASS DOOR LOCK DRIVER DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR) DRIVER DOOR SWITCH (IN LEFT "B" PILLAR) GRN (OR BLU) WIRE GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES I/P-A I/P-B I/P-C I/P-D I/P-E I/P-F INSTRUMENT CLUSTER INSTRUMENT PANEL JUNCTION BOX (UNDER LEFT SIDE OF DASH) KEY REMIND SW KEYLESS ENTRY RECEIVER (IF EQUIPPED) (UNDER GLOVE COMPARTMENT) LEFT REAR DOOR LOCK ACTUATOR (IN RIGHT (AT REAR "B" PILLAR) OF LEFT REAR DOOR) LOCK SWITCH MUX ORG/ WIRE ORG/BLK WIRE PASS DOOR UNLCK SW PASSENGER DOOR SWITCH (IN RIGHT "B" PILLAR) PASSENGER POWER WINDOW, POWER DOOR PNK (OR BLU) WIRE PNK (OR GRN) WIRE PNK PNK 1 2 WIRE PNK WIRE POWER CONNECTOR POWER WINDOW MAIN SWITCH REAR DOOR LOCK RED WIRE RED/BLK WIRE RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) RKE FUSE BCM ROOM FUSE SRF/D LOCK FUSE TAILGATE LOCK ACTUATOR (5 DOOR) (CENTER REAR OF TAILGATE) TWO TURN UNLOCK RELAY TWO TURN UNLOCK RELAY CONTROL W/ BURGLAR ALARM W/O BURGLAR ALARM WHT WIRE YEL/BLK WIRE YEL/ORG WIRE
