Shift interlock circuit for Kia Spectra I (2000-2001)
Shift interlock circuit
A/T SHIFT INTERLOCK CONTROL UNIT (IN FLOOR CONSOLE)
BATTERY INPUT
BLK WIRE
BRAKE PEDAL SWITCH (BELOW LEFT SIDE OF DASH)
BRAKE PEDAL SWITCH INPUT
ECU FUSE
FUSE BOX (BEHIND LEFT KICK PANEL)
GRN/YEL WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION ON INPUT
PNK WIRE
PNK/BLK WIRE
RED/BLK WIRE
SC-02 (BEHIND LEFT SIDE OF DASH)
SC-06 (BEHIND LEFT SIDE OF DASH)
STOP FUSE
TCU FUSE
W/ CRUISE W/O CRUISE
X-05
YEL/RED WIRE
