Headlight circuit, without drl for Kia Spectra I (2000-2001)
Headlight circuit, without drl
BLK WIRE
BLU WIRE
BRN WIRE
C-01
C-01 INSTRUMENT CLUSTER
E-01
E-01 COMBINATION SWITCH
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
EXTERIOR LIGHTS SYSTEM (TAIL FUSES)
HEAD FUSE
HEAD HI FUSE
HEADLIGHT RELAY
HI BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON OR ACC
JB-01 PNK WIRE
JB-02
JB-02 ENGINE COMPARTMENT FUSE/RELAY BOX HEAD LOW FUSE
JB-06
LEFT HEADLIGHT
LO HI
PASS
PNK WIRE
RED WIRE
RIGHT HEADLIGHT
S/C-01 (BEHIND LEFT KICK PANEL)
S/C-11 (BEHIND INSTRUMENT CLUSTER)
TNS FUSE
TNS OFF HEAD
TNS RELAY
WHT WIRE
YEL WIRE
