Anti-lock brake circuits for Kia Spectra I (2000-2001)

Anti-lock brake circuits

Get access

ABS CONTROL UNIT (LEFT REAR OF ENGINE COMPARTMENT) ABS FUSE ABS INDICATOR ABS WARNING RELAY (BEHIND LEFT SIDE OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE INDICATOR BRN WIRE BRN/BLU WIRE BRN/RED WIRE DATA LINK CONNECTOR (LEFT SIDE OF ENGINE COMPT) EBD WARNING RELAY (BEHIND LEFT SIDE OF DASH) ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT) FUSE BOX (BEHIND LEFT KICK PANEL) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER LEFT FRONT WHEEL SENSOR (AT LEFT FRONT WHEEL) LEFT REAR WHEEL SENSOR (AT LEFT REAR WHEEL) LT GRN/BLU WIRE LT GRN/RED WIRE LT GRN/YEL WIRE METER FUSE NCA WIRE RED/BLK WIRE RIGHT FRONT WHEEL SENSOR (AT RIGHT FRONT WHEEL) RIGHT REAR WHEEL SENSOR (AT RIGHT REAR WHEEL) SHORT CONNECTOR STOP FUSE STOP- LIGHT SWITCH (ABOVE BRAKE PEDAL) WHT WIRE WHT/YEL WIRE YEL WIRE
