Kia Spectra I (2000-2001) trunk room lamp Wiring diagram
This page shows the only wiring diagram for the component.trunk room lamp, which is found in the car Kia Spectra I (2000-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk room lamp (1 of 1)
B/DOOR INDIC- ATOR
BLK WIRE
C-01
DOOR INDIC- ATOR
FUSE BOX (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JB-01 PNK PNK WIRE
LEFT
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH
LT GRN WIRE
PERSONAL LAMP
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT REAR DOOR SWITCH RIGHT FRONT DOOR SWITCH
ROOM FUSE
ROOM LAMP
ROOM LAMP AND SUNROOF SWITCH
ROOM SW
S/C-01 (BEHIND LEFT KICK PANEL)
S/C-04 (BEHIND LEFT KICK PANEL)
SC-06 (BEHIND LEFT KICK PANEL)
SEPHIA
SPECTRA
SPOT SW
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH TRUNK ROOM LAMP SWITCH
YEL WIRE
Go to component -> Courtesy lamps circuit -> TRUNK ROOM LAMP
