Kia Spectra I (2000-2001) s/c-08 (behind instrument cluster Wiring diagram
This page shows the only wiring diagram for the component.s/c-08 (behind instrument cluster, which is found in the car Kia Spectra I (2000-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram s/c-08 (behind instrument cluster (1 of 1)
A-05 GENERATOR
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE INDIC- ATOR
BRN WIRE
BRN/WHT WIRE
C-01
COMBINATION SWITCH
DRL RELAY (BEHIND LEFT SIDE OF DASH)
DRL UNIT (BEHIND LEFT SIDE OF DASH)
E-01
ENGINE COMPARTMENT FUSE/RELAY BOX (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
ENGINE COMPT FUSE/ REALY BOX (AT LEFT REAR SIDE OF ENGINE COMPT)
EXTERIOR LIGHTS SYSTEM (TAIL FUSE)
FUSE
FUSE BOX (BEHIND LEFT KICK PANEL)
GRN WIRE
HEAD FUSE
HEAD HI FUSE
HEAD LOW FUSE
HEADLIGHT RELAY
HI BEAM INDIC- ATOR
HOT AT ALL TIMES
HOT AT ON
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT CLUSTER
JB-01
JB-02
JB-02 JB-01
JB-06
LEFT HEADLIGHT
LO HI PASS
METER FUSE
PARKING BRAKE SWITCH
PNK WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RIGHT HEADLIGHT
S/C-01 (BEHIND LEFT KICK PANEL)
S/C-08 (BEHIND INSTRUMENT CLUSTER
S/C-11 (BEHIND INSTRUMENT CLUSTER)
SC-06 (BEHIND LEFT KICK PANEL)
SR-
TCU FUSE
TNS FUSE
TNS OFF HEAD
TNS RELAY
WHT WIRE
X-17
YEL WIRE
YEL/RED WIRE
Go to component -> Headlight circuit, with drl -> S/C-08 (BEHIND INSTRUMENT CLUSTER
