Kia Spectra I (2000-2001) maf sensor input vehicle speed in crank position sensor camshaft sensor input Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 PNK PNK WIRE A/C SYSTEM BLK WIRE BLK/LT GRN WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COIL FUSE CONDENSER COOLING FANS SYSTEM CRANK POSITION SENSOR ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROL MODULE (BELOW RIGHT CENTER OF DASH) EVAP CAN PURGE VLV FRONT FUEL INJECTORS FUEL PUMP (IN FUEL TANK) FUEL PUMP FUSE FUEL PUMP RELAY FUSE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON, START HOT IN START IGNITION COILS IGNITION CONTROL IGNITION INPUT IGNITION GROUND INJ FUSE INJECTOR 3 CTRL INJECTOR 2 CTRL INJECTOR GROUND JB-01 JB-02 JB-05 LEAK DETECTION PMP CTL LEAK DETECTION VLV CTL LT GRN/BLK WIRE LT GRN/YEL WIRE MAF SENSOR GND MAF SENSOR INPUT VEHICLE SPEED IN CRANK POSITION SENSOR CAMSHAFT SENSOR INPUT MAIN RELAY MIL CONTROL LEAK DET PUMP ORG/BLK WIRE OUTPUT STAGE GROUND PNK WIRE PNK/BLK WIRE PURGE SOLENOID VALVE (CENTER REAR OF ENGINE COMPT) REAR RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SPARK PLUGS STARTER FUSE TACHOMETER OUT A/C RELAY CNTRL THROTTLE POSITION OUT TRANS- MISSIONS SYSTEM VIO/WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE
