Kia Spectra I (2000-2001) left front combi- nation lights left rear combi- nation lights Wiring diagram
This page shows the only wiring diagram for the component.left front combi- nation lights left rear combi- nation lights, which is found in the car Kia Spectra I (2000-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front combi- nation lights left rear combi- nation lights (1 of 1)
A/C SWITCH
A/T SHIFT INTERLOCK CONTROL UNIT
ABS CONTROL UNIT
ABS FUSE
ABS FUSE BTN FUSE ABS FUSE
ABS WARNING RELAY
AUDIO
AUDIO FUSE
AUTO CLOCK
BACK-UP LIGHT SWITCH
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CIGAR FUSE
CIGAR LIGHTER
DOOR LOCK RELAY
DOOR LOCKS FUSE
DRL UNIT
ELECTRONIC TIME, WARNING INDICATION SYSTEM
ELECTRONIC TIME, WARNING INDICATION SYSTEM MODULE
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT REAR SIDE OF ENGINE COMPT)
FROM ENGINE COMPARTMENT FUSE/RELAY BOX (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FUSE BOX (BEHIND LEFT KICK PANEL)
GRN WIRE
HAZARD FUSE
HAZARD SWITCH
INSTRUMENT CLUSTER
INTAKE SWITCH REAR DE- FROSTER SWITCH
JB-01
JB-02
JB-03 JB-02
JB-06
LEFT FRONT COMBI- NATION LIGHTS LEFT REAR COMBI- NATION LIGHTS
LEFT LICENSE LIGHT (SEPHIA)
LEFT POSITION LIGHT
LH TAIL FUSE
METER FUSE
PNK PNK WIRE
PNK WIRE
PNK/BLU WIRE
POWER MIRROR SWITCH
POWER WINDOW MAIN SWITCH MODE SWITCH
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RH TAIL FUSE
RIGHT LICENSE LIGHT (SEPHIA)
RIGHT POSITION LIGHT RIGHT FRONT COMBI- NATION LIGHTS
RIGHT REAR COMBI- NATION LIGHTS LICENSE LIGHT (SPECTRA)
ROOM FUSE
SC-02
SC-04
SC-06
SC-08
SC-09
SC-11
TCU FUSE
TO FUSE BOX (DIAGRAM 2 OF 3)
TO SC-06 (DIAGRAM 2 OF 3)
TRANSAXLE CONTROL MODULE
TRANSAXLE RANGE SWITCH
TURN FUSE
VEHICLE SPEED SENSOR
W/O DRL W/ DRL
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> LEFT FRONT COMBI- NATION LIGHTS LEFT REAR COMBI- NATION LIGHTS
