Tire pressure monitoring circuit for Kia Soul III facelift (2022-2024)

Tire pressure monitoring circuit

Get access

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BRN WIRE C-CAN CLUSTER FUSE COMPUTER DATA LINES SYSTEM DC-DC HOT IN ON OR START IBU ICU JUNCTION BLOCK ICU-E INSTRUMENT CLUSTER INTERFACE LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MICOM ON/START INPUT PNK WIRE PNK/BLK WIRE POWER GND RED WIRE RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR TPMS (YELLOW) IND TRANSCEIVER/ WHT WIRE
