Power windows circuit, w/ driver auto down power window for Kia Soul III facelift (2022-2024)
Power windows circuit, w/ driver auto down power window (1 of 2)
AUTO DOWN
BLK WIRE
BLU WIRE
BRN WIRE
CONTROL UNIT)
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DRIVER POWER WINDOW MOTOR
DRIVER WINDOW SWITCH
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ILL
IPS CONTROL MODULE
LEFT POWER WINDOW RELAY
LEFT REAR WINDOW SWITCH
OFF
ORG/ WIRE
P/WINDOW LH FUSE
P/WINDOW RH FUSE
PASSENGER WINDOW SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH
PWR WINDOW RELAY CONTROL
RED WIRE
RIGHT POWER WINDOW RELAY
RIGHT REAR WINDOW SWITCH
WHT WIRE
WINDOW LOCK SWITCH
YEL WIRE
Power windows circuit, w/ driver auto down power window (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HIGH IND
ILL
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LOW IND
OFF
OFF UP
ORG/ WIRE
PASSENGER POWER WINDOW MOTOR
PASSENGER POWER WINDOW SWITCH
PNK WIRE
RED WIRE
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SEATS SYSTEM
UP OFF
W/ REAR SEAT WARMER W/O REAR SEAT WARMER
W/O REAR SEAT WARMER W/ REAR SEAT WARMER
WHT WIRE
YEL WIRE
