Parking assistant circuit for Kia Soul III facelift (2022-2024)
Parking assistant circuit (1 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DISTANCE
GRN WIRE
GRY WIRE
HOT IN ON OR START
IBU
ICU JUNCTION BLOCK
ICU-E
ILL
LEFT FORWARD PARKING DISTANCE WARNING
LEFT FORWARD PARKING DISTANCE WARNING (CENTER)
LIN
MODULE 4 FUSE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PARKING
PAS OPT IN
PDW FWD PWR
PDW REV PWR
PDW SENSOR PWR
PDW SW IND
PDW SW MODE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FORWARD PARKING DISTANCE WARNING
RIGHT FORWARD PARKING DISTANCE WARNING (CENTER)
WARNING SWITCH
YEL WIRE
Parking assistant circuit (2 of 2)
AMP
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN TRANSCEIVER
COMPUTER DATA LINES SYSTEM
DC-DC
INSTRUMENT CLUSTER
LEFT REVERSE PARKING DISTANCE WARNING
LEFT REVERSE PARKING DISTANCE WARNING (CENTER)
LIN
M-CAN TRANSCEIVER
MICOM
PNK/BLK WIRE
RED WIRE
RIGHT REVERSE PARKING DISTANCE WARNING
RIGHT REVERSE PARKING DISTANCE WARNING (CENTER)
SPEAKER
WHT WIRE
YEL WIRE
