Kia Soul III facelift (2022-2024) t/turn unlk rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.t/turn unlk rly ctrl, which is found in the car Kia Soul III facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram t/turn unlk rly ctrl (1 of 1)
BACKUP GROUND
BLK WIRE
BLU WIRE
BRN WIRE
DOOR LK SW
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR LOCK RLY CTRL
DOOR LOCKS, ANTI-THEFT SYSTEMS
DOOR UNLOCK RELAY
DOOR UNLOCK RLY CTRL
DR LK/UNLK SIG
DRV PASS
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HMSL
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-B
ICU-C
ICU-D
ICU-E
ICU-F
ICU-G
IPS CONTROL MODULE
IPS CTRL
LEFT POWER WINDOW RELAY
LEFT STOP LAMP
LONG TERM LOAD LATCH RELAY
LONG TERM LOAD LATCH RLY CTRL
MAIN GROUND
MEMORY POWER
ORG/ WIRE
P/WINDOW LH FUSE
P/WINDOW RH FUSE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER WINDOW RLY CTRL
POWER WINDOWS SYSTEM
RED WIRE
RIGHT POWER WINDOW RELAY
RIGHT STOP LAMP
SAFETY ENABLE
SEATS SYSTEM
STEERING HEAT
STEERING WHEEL HEATER NTC (-)
STEERING WHEEL HEATING SWITCH IPS IND CTRL SWITCH
STOP LAMP SIG
T/TURN UNLK RLY CTRL
TAILGATE HANDLE B+2 SW
TAILGATE LAMP SW
TAILGATE OPEN FUSE
TRUNK RELAY
TRUNK RLY CTRL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLK RR
WHT WIRE
YEL WIRE
Go to component -> Ips control module circuit (1 of 2) -> T/TURN UNLK RLY CTRL
